ROQ-3405 | OEM/ODM Customized Logo RO Purifier Water Filter System, 5-Stage 50 75GPD Quick Change Under Sink Machine, FI Filter, EZ Quick Connector
Item No：ROQ-3405
SHARE：
- Patented quick change filter design
- Five stages filter cartridges
- Without booster pump
- With shut-off valve
- In-line filter, R.O. membrane, and storage tank are all certified with NSF
- Capacity: 50 GPD
- Waste water ratio: 1:3
- Flow rate : 1.5liter/min
- Applicable Pressure:50~80PSI
- Please install a pressure reducing valve if the water pressure exceeds 60 PSI.
Request
Feature
- Quick change filter design, easy to replace the filter cartridge
- EZ quick connect connector design, easy to install and replace fittings
- Membrane housing designed with 2 o-rings to ensure durability and prevent water leak
- Powder coating metal bracket to avoid get rusty
- The system passed 100,000 times cycle test under 150 PSI water pressure
- Functional components also passed cycle and burst test which conform to NSF test protocol
- Water contact components are produced with all raw materials
- 100% leak test before delivery
- Made in Taiwan
| 型號 |
ROQ-3405 |
| Cartridge Stages |
5 Stages |
| Booster Pump | NON |
| Transformer | NON |
| Cartridge Type | QCC-type quick change cartridge |
| Membrane(gallon) NSF |
NSF 50/75/100GPD(NSF) Optional |
| Shutoff Valve | 1/4"FIP |
| Drain Ratio | 1:3 |
| Water Output Flow | 1.5 LPM |
| PE Tube Size |
1/4"OD(6.35φ m/m) |
| Fitting Connect |
1/4" Quick connector |
| Storage Tank |
Metal 4 gallons |
| able water pressure | 50-80PSI |
| Dimensions | L386xW145xH392 (mm) |
| Weight | 7.5KG |
Specification
| Model No. | Filter quantity | WATER FILTER | Weight (incl. tank) | Cu'ft |
| ROQ-3404 | 4 STAGES | Quick Change Filters | 4 kgs | 0.78 cu.ft |
| ROQ-3405 | 5 STAGES | AIC-10 | 4.5 kgs | 1 cu.ft |
Cartridges:
| Stage | Model No. | Media | Function |
| 1st | QCC-10P | PP sediment, 5 µ | Remove dirt, sand and other sediment |
| 2nd | QCC-10C | GRANULAR ACTIVATED CARBON (GAC) | Reduce chlorine, taste & odor |
| 3rd | QCC-10P | PP sediment, 1 µ | Remove dirt, sand and other sediment |
| 4th | MBS-1050 | 50 GPD membrane, NSF | Remove virus, bacteria, heavy metal, etc. |
| 5th | AIC-10 | Coconut GAC, NSF | Have better tasting of water |
| ITEMS |
ROQ-3405 |
| Cartridge Stages |
5 Stages |
| Booster Pump | NON |
| Transformer | NON |
| Cartridge Type | QCC-type quick change cartridge |
| Membrane(gallon) NSF |
NSF 50/75/100GPD(NSF) Optional |
| Shutoff Valve | 1/4"FIP |
| Drain Ratio | 1:3 |
| Water Output Flow | 1.5 LPM |
| PE Tube Size |
1/4"OD(6.35φ m/m) |
| Fitting Connect |
1/4" Quick connector |
| Storage Tank |
Metal 4 gallons |
| able water pressure | 50-80PSI |
| Dimensions | L386xW145xH392 (mm) |
| Weight | 7.5KG |
Assembly
| Spare parts | Model No. | Spec. |
| Membrane housing | HM-256 | White, 1/8"NPTx1/8"NPT |
| Storage tank | TANK-4MW (NSF) | 4 gallon, metal white |
| Shut-off valve | RO-S001 | White, 1/4" Jaco type |
| Drinking faucet | ZWDF-1002 | Quarter-turned spout, 3" shank, lead-free |
| Flow restrictor | FRB-450 | bead type, 450ml, green color |
Accessories
| Spare parts | Model No. | Spec. |
| Water feed adaptor | BV-1414L | 1/4" ball valve with 1/2"MIPx1/2"FIP water feed fitting |
| Wrench | HAN-01W | Plastic White |
| PE tube | PE-14W-NSF | 1/4" tube, white, NSF |
| Ball valve for tank | BV-8P | Plastic, 1/4" Jaco |
Package
| Carton box type | Package |
| Export standard carton box | System and tank are packed seperated |
Containers
| Container Dimension | Cu'ft | Quantity |
| 20ft | 1,172 CU'FT | 500PCS |
| 40ft | 2,385 CU'FT | 1040PCS |
| 40'HQ | 2,690 CU'FT | 1200PCS |
Others
- Quick-fitting type system is optional
- Manual flush valve is optional
Certificates
| Verification Of Conformity With European LVD Directive-(ROQ-3405) | ||
 |
