ROQ-3815H | OEM/ODM Customized Logo RO Purifier Water Filter System, 5-Stage 50 75 100GPD NSF Membrane Quick Change Under Sink Machine with Pump,White
SHARE：
- Patented quick change filter design
- Five stages filter cartridges
- With booster pump/transformer(110V or 220V 24VDC)
- With shut-off valve
- Capacity: 50gallons per day
- Waste water ratio: 1:3
- Flow rate : 1.5liter/min
- Applicable Pressure:≦50PSI
- Please install a pressure reducing valve if the water pressure exceeds 60 PSI.
- Quick change filter design, easy to replace the filter cartridge
- In-line filter, R.O. membrane, and storage tank through NSF Certification.
- STAND TYPE BRACKET, wall-mounting/stand design
- EZ quick connect connector design, easy DIY to install and replace by yourself
- Using the Magnet Wire transformer to ensure stable voltage,
- The membrane housing has a double O-ring design to ensure durability and no leakage
- Powder steel plate coating, it is not easy to rust
- Completed set & functional components have been passed 300 PSI (15 minutes)~500 PSI (instantaneous) burst test & 100,000 times cycle test under 150 PSI water pressure(conform to NSF test criteria)
- 100% pure raw materials for spare parts contacted water.
- Before shipment, all pass 100% leaking test
- Made in Taiwan
|
ITEMS |
ROQ-3815 |
|
Cartridge Stages |
5 Stages |
|
Booster Pump |
50 GPD, 24VDC |
|
Cartridge Type |
QPP Quick Change Filters |
|
Fitting Connect |
1/4" Quick connector |
|
Water Output Flow |
1.5 LPM |
|
PE Tube Size |
1/4"OD |
|
Storage Tank |
Metal 4 gallons |
|
Applicable water pressure |
≦50PSI |
|
Dimensions(noncontain) |
L30x W17 x H42(cm) |
|
Weight |
10.5KG(contain tank) |
| Model No. | Fitting Type | Weight (incl. tank) | Cu'ft |
| ROQ-3815(H) | JACO | 9 kgs | 1.1 cu.ft |
Cartridges:
| Stage | Model No. | Media | Function |
| 1st | QCC-10P | PP sediment, 5 µ | Remove dirt, sand and other sediment |
| 2nd | QCC-10C | GRANULAR ACTIVATED CARBON (GAC) | Reduce chlorine, taste & odor |
| 3rd | QCC-10P | PP sediment, 1 µ | Remove dirt, sand and other sediment |
| 4th | MBS-1050 | 50 GPD membrane, NSF | Remove virus, bacteria, heavy metal, etc. |
| 5th | AIC-10 | Coconut GAC, NSF | Have better tasting of water |
|
ITEMS |
ROQ-3815 |
|
Cartridge Stages |
5 Stages |
|
Booster Pump |
50 GPD, 24VDC |
|
Cartridge Type |
QPP Quick Change Filters |
|
Fitting Connect |
1/4" Quick connector |
|
Water Output Flow |
1.5 LPM |
|
PE Tube Size |
1/4"OD |
|
Storage Tank |
Metal 4 gallons |
|
Applicable water pressure |
≦50PSI |
|
Dimensions(noncontain) |
L30x W17 x H42(cm) |
|
Weight |
10.5KG(contain tank) |
Assembly
| Spare parts | Model No. | Spec. |
| Membrane housing | HM-256 | White, 1/8"NPTx1/8"NPT |
| Storage tank | TANK-4MW (NSF) | 4 gallon, metal white |
| Shut-off valve | SD-11024/22024 | White, 1/4" Jaco type |
| Drinking faucet | ZWDF-1002 | Quarter-turned spout, 3" shank, lead-free |
| Flow restrictor | FRB-450 | bead type, 450ml, green color |
| PUMP | PUMP-5024DC | 50 GPD, 24VDC |
| VOLTAGE | TRAN-22024DC | 100~240/24VDC,1.2A, ROUND PLUG |
Accessories
| Spare parts | Model No. | Spec. |
| Water feed adaptor | BV-1414L | 11/4" ball valve with 1/2"MIPx1/2"FIP water feed fitting |
| PE tube | PE-14W-NSF | 1/4" tube, white, NSF |
| Ball valve for tank | BV-8P | Plastic, 1/4" Jaco |
Package
| Carton box type | Corrugated box |
| Package | System and tank are packed seperated |
Containers
| Container Dimension | Cu'ft | Quantity |
| 20ft | 1,172 CU'FT | 380PCS |
| 40ft | 2,385 CU'FT | 755PCS |
| 40'HQ | 2,690 CU'FT | 880PCS |
Others
￭ Quick-fitting type system is optional
￭ Manual flush valve is optional
￭ Pressure gauge is optional
