ROT-816 | OEM/ODM Customized Commercial RO Purifier Water Filter System, 6-Stage 150 GPD NSF Membrane Whole House Under Sink Machine, Restaurant Use
SHARE：
- 6 stages filter
- 300 GPD booster pump with transformer:110V or 220V 24VDV
- Solenoid valve
- With NSF certificate：in-line post coconut carbon cartridge and membrane
- Capacity：150GPD
- Waste water ratio： 1:3
- Pure water flow rate：1.5 LPM
- Operating pressure:： ≦50PSI
- Please install a pressure reducing valve if the water pressure exceeds 60 PSI.
-
Using magnet wired transformer to stabilize voltage, ensure durability and keep from overheating
- Powder coating metal bracket to avoid get rusty
-
The system passed 100,000 times cycle test under 150 PSI water pressure
-
Functional components also passed cycle and burst test which conform to NSF test protocol
-
Water contact components are produced with all raw materials
-
100% leak test before delivery
-
Made in Taiwan
|
ITEMS |
ROT-816 |
| Cartridge Stages |
6 Stages |
|
Cartridge Type |
20" Standard Filter |
|
RO Output |
300GPD (NSF) |
|
Booster Pump |
300GPD 36VDC |
|
Transformer |
110 or 220V, 36VDC, 1.8A |
|
Solenoid Valve |
1/4"FIP x 1/4"FIP |
|
Drain Ratio |
1:3 |
|
Water Output Flow |
1.5 LPM |
|
PE Tube Size |
1/4"OD(6.35φ m/m) |
|
Fitting Connect |
1/4" JACO & Quick connector |
|
Applicable Pressure |
20~50PSI |
|
Dimensions (w/o tank) |
L250xW450xH670 (mm) |
| Model No. | flow rate | Weight (incl. tank) | Cu'ft |
| ROT-816 | 150 | 23kgs | 4.8cu.ft |
Cartridges:
| Stage | Model No. | Media | Function |
| 1st | PP20-05 | PP sediment, 5 µ | Remove dirt, sand and other sediment |
| 2nd | CBC-20CTO | Carbon Block | Reduce chlorine, taste & odor |
| 3rd | PP20-01 | PP sediment, 1 µ | Remove dirt, sand and other sediment |
| 4th~5th | MBS-1075 | 75 GPD membrane*2 , NSF | Remove virus, bacteria, heavy metal, etc. |
| 6th | AIC-10 | Coconut GAC, NSF | Have better tasting of water |
|
ITEMS |
ROT-816 |
| Cartridge Stages |
6 Stages |
|
Cartridge Type |
20" Standard Filter |
|
RO Output |
400GPD (200GPD x 2PCS) (NSF) |
|
Booster Pump |
300GPD 36VDC |
|
Transformer |
110 or 220V, 36VDC, 1.8A |
|
Solenoid Valve |
1/4"FIP x 1/4"FIP |
|
Drain Ratio |
1:3 |
|
Water Output Flow |
1.5 LPM |
|
PE Tube Size |
1/4"OD(6.35φ m/m) |
|
Fitting Connect |
1/4" JACO & Quick connector |
|
Applicable Pressure |
20~50PSI |
|
Dimensions (w/o tank) |
L250xW450xH670 (mm) |
Assembly
| Spare parts | Model No. | Spec. |
| Housing | HE2038LB-UR | 20" Blue housing, 3/8" black round RIB cap, with pressure release |
| Membrane housing | HM-256 | White, 1/8"NPTx1/8"NPT |
| Solenoid valves | SD-P1436DC | 1/4"FIP 36VDC Plastic |
| Flush valve | BV-9P/1000 | Straight 1/4"E-Z+Flow restrictor1000 |
| Pump | PUMP-30036DC-CE | 300GPD/36VDC |
| Voltage | TRAN-22036DC | 220/24VDC,1.8A, round plug |
| High pressure switch | SWI-H | 1/4"JACO 2P |
| Low pressure switch | SWI-L | 1/4" FNPT |
Accessories
| Spare parts | Model No. | Spec. |
| Water feed adaptor | BV-1438L | 3/8" Ball valve with 1/2"MIPx1/2"FIP water feed fitting |
| Wrench | HAN-01W | Plastic White |
| PE tube | PE-14W-NSF & PE-38W-NSF | 1/4" tube & 3/8" tube, white, NSF |
Package
| Carton box type | Package |
| Export standard carton box | System and tank are packed seperated |
Containers
| Container Dimension | Cu'ft | Quantity |
| 20ft | 1,172 CU'FT | 245 PCS |
| 40ft | 2,385 CU'FT | 420 PCS |
| 40'HQ | 2,690 CU'FT | 570 PCS |
Others
- 11 gallon tank is optional
- Drinking Faucet is optional
- Manual flush valve is optional
- Pressure gauge is optional
- Waste water ratio： 1:2 is optional
