WATER PURIFIER

Item No:CWF-A101C

SHARE:

  • Countertop design
  • Equipped with a 10" normal cartridge
  • With 10" AS transparent housing
  • Pure water flow rate:1.4 LPM
Color
Dim.
L20xW13xH32(cm)
Quantity
Min. order>pcs
Request
Feature
  1. 10" normal  cartridge design let you can choose a cartridge with diverse function you request
  2. 100% brass diverter valve with the design of large water flow. Besides, internal water-stop structure is designed with Teflon spherical material to ensure our products is non-toxic and resistant.
  3. PVC tube is non-toxic, non-odor and non-faded
  4. Membrane housing has passed 100,000 times strict cycle testing under 150PSI water pressure and 300 PSI burst test to make sure it’s durable.
  5. All pass NSF test standard.
  6. 100% pure raw materials for spare parts contacted water.
  7. Before shipment all pass 100% leaking test
  8. Made in Taiwan
Specification
Model No. Stage Housing Packing Weight Cu'ft
CWF-A101C Single AS Clear 8 pcs 13kgs 2.1 cu.ft
CWF-A101W Single PP White 8 pcs 13kgs 2.1 cu.ft



Cartridges(optional):

Model No. Media Function
PP10-05 PP sediment, 5 µ Remove dirt, sand and other sediment
CBC-5CTO Carbon Block Reduce chlorine, taste & odor
CC-5C Coconut GAC Reduce chlorine, taste & odor



Assembly

Spare parts Model No. Spec.
Housing HA1014CW-C or HA1014WW-C 10" PP White or Clear Housing, 1/4" White Flat Cap
Diverter valve DVB-38CQ 3/8" Quick Connector, Brass
Water inlet fitting C-21-1  1/4"MIP, Brass
Water outlet fitting C-24 1/4"MIPx3/8"BARB, Brass
Spout CS-8-2-OW 8" Curved Spout With 2 O-Ring, Copper



Accessories

Spare parts Model No. Spec.
External Faucet Adapter ETA-02 55/64"-27 with stainless steel collar
Internal Faucet Adapter AD1C+AD2C 15/16"-27 & 13/16"-27 * 55/64"-27, Brass
Wrench HAN-01 Plastic, White
PVC tube PVC-14W 1/4" tube, white, 3 feet



Containers

Container Dimension Cu'ft Quantity
20ft 1,172 CU'FT PCS
40ft 2,385 CU'FT PCS
40'HQ 2,690 CU'FT PCS


Others

■ 1/4"Elbow for in/outlet is optional
■ MOUNTING BRACKET is optional

Certificates
